AIS2001 | 4 x GE, 2 x GE SFP

Overview
The AIS2001 is a compact, industrial-grade Layer 2+ managed switch featuring 4×10/100/1000Mbps RJ45 ports and 2×1Gbps SFP slots for flexible uplink connectivity. Built for harsh environments, it operates reliably in extreme temperatures ranging from -40°C to 75°C and is housed in a fanless, all-aluminum enclosure for efficient heat dissipation and corrosion resistance. The switch supports static routing, VLAN, QoS, and ring protection protocols such as STP, RSTP, MSTP, and ERPS, ensuring resilient network performance and fast recovery in industrial applications. Additional features include dual power input support, lightning and ESD protection, and multiple management options via Console, Telnet, SSH, and Web interfaces—making it ideal for smart manufacturing, transportation, and other mission-critical deployments.

Specifications
Spec
Details
Interface
4 x GE | 2 x GE SFP
Management Port
1 x Console Port
Chipset
Realtek
Mac Address Table
8 K
Packet Forwarding Rate
8.92 Mpps
Switching Capacity
12 Gbps
Flash
32 MB
Memory
128 MB
Power Supply
DC:12-55 V
Operating Temperature
−40 °C – 75 °C (−40 °F – 167 °F)
Storage Temperature
−40 °C – 80 °C (−40 °F – 176 °F)
Surge Protection
Differential mode ±2KV, Common mode ±6KV
Electrostatic Standards
Contact ±6KV, Air ±8KV
Dimensions (L x W x H)
4.33" x 3.66" x 2.84" (110 x 93 x 72 mm)
Installation
DIN-rail Mount or Wall Mount
Accessories
Phoenix Terminal*2, Console Cable*1

Certifications
