AES4102P | 24 x 2.5 GE, 2 x 10 GE, 4 x 10 GE SFP+, L3 PoE+

Overview
The AES4102P is a robust, enterprise-grade managed Ethernet switch designed to meet the demands of modern networks across commercial and educational environments. Built for high reliability and seamless integration, it supports advanced traffic management, secure segmentation, and centralized control through AURC-NOS using ACC & ACN platforms.

Whether deployed in structured enterprise settings, the AES4102P delivers consistent performance, simplified wiring, and resilient operation. Its PoE+ capabilities, surge protection, and flexible uplink options make it a versatile backbone for powering and connecting critical devices across distributed infrastructures.

Specifications
Spec
Detail
Interface
24 x 2.5 GE | 2 x 10 GE | 4 x 10 GE SFP+ | L3 PoE+
Management Port
1 x Console Port
Chipset
Realtek
Mac Address Table
32 K
Packet Forwarding Rate
178.56 Mpps
Switching Capacity
240 Gbps
Flash
32 MB
Memory
4 Gb
PoE Standard
IEEE 802.3af/at
Power Supply
438 W
Power Consumption
Idling：115Vac/60Hz  30.7W
Idling：230Vac/50Hz  30.3W
Full load：115Vac/60Hz  470.6W
Full load：230Vac/50Hz  456.8W
PoE Budget
370 W
Operating Temperature
0 °C – 40 °C (32 °F to 104 °F)
Storage Temperature
-40 °C – 70 °C (-40 °F to 158 °F)
Surge Protection
Differential mode ±4KV, Common mode ±6KV
Electrostatic Standards
Contact ±6KV, Air ±8KV
Dimension(L*W*H)
17.32" × 10.24" × 1.73" (1U Height)
Installation
Rack Mount or Desktop Mount
Accessories
Rack Mount Kit *2, Rubber Feet *4, Screw *8,
Console Cable *1, Power Cord *1

Certifications
