AES8001 | 32 x 400GE, 2 x SFP+

Overview
The AES8001 delivers high-throughput, low­latency switching optimized for spine-layer deployments in modern data centers. Its space-efficient 1 RU form factor supports line-rate Layer 2 and Layer 3 switching across 32 x 400GE QSFP-DD, 2 x 10GE SFP+ ports.

Pre-loaded with the Open Network Install Environment (ONIE), the AES8001 enables flexible installation of industry-standard Network Operating Systems, including both open-source platforms such as SONiC and commercial NOS solutions for enterprise­grade functionality.

Specifications
Spec
Details
Interface
32 × 400GE QSFP-DD | 2 x 10GE SFP+
Managment Port
1 x MGMT Port, 1 x Console Port, 1 USB Port (USB 3.0)
Chipset
Marvell
Switching Capacity
25.6 Tbps
Packet Forwarding Rate
5600 Mpps
System Memory
16 GB
Dimensions (L x W x H)
24.80"(L) × 17.32"(W) × 1.73"(H) / 1U height
Full Weight
15kg / 33.07 lbs.
Fan
7 hot-swappable fan modules for front/rear ventilation
Power Supply
2 (1+1 redundancy), hot-swappable
AC Input
Rated voltage range: 100~240 V
Maximum voltage range: 90~264 V
Frequency: 50~60 Hz
Rated input current: 0~10 A(230VAC); 0~12 A(100VAC)
DC Input
Input voltage range: 180~310 V
Input current range: 0-10 A
Operating Temperature
0 °C  to  40 °C (32 °F to 104 °F)
Storage Temperature
-40 °C  to  70 °C (-40 °F to 158 °F)
Installation
Rack Mount
Accessories
Mounting Bracket*2, Screw*6, Grounding Cable*1,
Grounding Screw*1, Console Cable*1, Power Cord*2
